This Rope is made from high tenacity Polypropylene Multifilament Yarns(PPMF). PPMF yarn has the best strength and best softness in the synthetic yarn category.(3-Ply) Polypropylene Multifilament Twisted Ropes
Handling, In Cargo Loading and Unloading Operations in all Ports.
For Line Stringing, Tower Erection, Transformer Hoisting and Material Handling.
Also use by Para-military Forces and Defense Production Establishments
| PP Multifilament ( 3 ply ) Twisted Ropes | |||||
|---|---|---|---|---|---|
| SIZE | 100 Meter Coil Weight in Kg. | 110 Meter Coil Weight in Kg. | 220 Meter Weight in Kg. | Runnage Meter in 1 Kg. | Breaking Strength Kgf |
| 2 mm | 0.130 | 0.145 | 0.300 | 740 Meter | 70 |
| 3 mm | 0.320 | 0.350 | 0.700 | 322 Meter | 132 |
| 4 mm | 0.800 | 0.880 | 1.750 | 125 Meter | 280 |
| 5 mm | 1.000 | 1.100 | 2.200 | 100 Meter | 520 |
| 6 mm | 1.660 | 1.830 | 3.660 | 60 Meter | 630 |
| 8 mm | 3.000 | 3.350 | 6.700 | 33 Meter | 1190 |
| 10 mm | 4.600 | 5.000 | 10.000 | 22 Meter | 1650 |
| 12 mm | 7.000 | 7.600 | 15.200 | 14.5 Meter | 2530 |
| 14 mm | 9.200 | 10.100 | 20.200 | 10.8 Meter | 3460 |
| 16 mm | 11.500 | 12.700 | 25.400 | 8.6 Meter | 4530 |
| 18 mm | 15.500 | 17.000 | 34.000 | 6.5 Meter | 5610 |
PP rope are generally packed individually coil in warping stretch film and then Coils are packed in woven bags for shipping.
All coils are pack in PP Bags and it's Packing to be done in our standard Woven Bag/ Fabric.
Bale No., Size, Length, Nos. of Coils, Weight are must written on Woven Bag.
Box Packing : In corrugated box net weight 30 kg. ( Approx)
